Compact structure, low noise and vibration
Environmental friendly, clean exhaust, smokeless and oil free
Easy maintenance, low operation cost
High quality material, advanced process and long durability
Pressure range: 0.1~2mbar
Pumping speed：10-630m3/h
Technical Data
Models | PX10 | PX16 | PX21 | PX25 | PX40 | PX63 |
Pumping speed (m3/h) | 10 | 16 | 20 | 25 | 40 | 63 |
Ultimate total pressure (mbar) | 2 | 2 | 1 | 0.5 | 0.5 | 0.5 |
Motor power (kw) | 0.37 | 0.55 | 0.75 | 0.75 | 1.1 | 1.5 |
Motor speed (r/min) | 2800 | 2800 | 2800 | 1450 | 1450 | 1450 |
Water vapor capacity (Kg/h) | 0.2 | 0.3 | 0.4 | 0.5 | 0.7 | 1 |
Noise (dB) | 62 | 63 | 64 | 64 | 64 | 64 |
Oil capacity (L) | 0.5 | 0.5 | 0.5 | 1 | 1 | 2 |
Inlet port (inch) | G1/2" | G1/2" | G1/2" | G1 1/4" | G1 1/4" | G1 1/4" |
Weight (kg) | 16 | 16 | 19 | 38 | 43 | 49 |
Dimension (L*W*H) | 308*215*207 | 308*215*207 | 421*232*218 | 580*286*266 | 605*308*266 | 620*405*280 |
Models | PX10 | PX16 | PX21 | PX25 | PX40 | PX63 |
Pumping speed (m3/h) | 100 | 160 | 200 | 250 | 300 | 630 |
Ultimate total pressure (mbar) | 0.5 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
Motor power (kw) | 2.2/3.0 | 4 | 4.0/5.5 | 5.5 | 5.5/7.5 | 15 |
Motor speed (r/min) | 1450 | 1450 | 1450 | 1450 | 1450 | 825 |
Water vapor capacity (Kg/h) | 1.5 | 2.5 | 4 | 4 | 4.5 | 26 |
Noise (dB) | 65 | 70 | 72 | 72 | 74 | 75 |
Oil capacity (L) | 2 | 6 | 6 | 8 | 8 | 25 |
Inlet port (inch) | G1 1/4" | G2" | G2" | G2" | G2" | DN100 |
Weight (kg) | 69 | 142 | 145 | 190 | 212 | 660 |
Dimension (L*W*H) | 710*405*290 | 761*495*411 | 795*495*411 | 965*585*411 | 1010*585*411 | 1488*888*752 |
Packaging
Semiconductors
Power engineering
Medicine technology
PV
Petroleum industry
Electrical engineering
Ceramic industry
Automotive industry
